CAN Demo Solution:

Introduction:

This solution adopts the MG32F02Nxxx as the main control MCU, which features a CAN interface. It enables stable and noise-resistant multi-node communication in applications such as industrial or automotive instruments, making it suitable for real-time control in harsh environments. Its high reliability and error detection capabilities effectively enhance overall system stability and scalability.

Features:

 - Supports 288 multi-segment LCD display with flexible COM/SEG pin mapping, reducing PCB layout complexity.

 - Supports UART/CAN bootloader, allowing in-system firmware updates via communication interfaces without disassembling the device, significantly simplifying production and maintenance processes.

 - Suitable for handheld instrument sensor applications, with built-in ADC, OPA, and PGA for detecting and amplifying small signals; ACMP for threshold setting; and DMA for fast data transfer.

 - Supports wide operating voltage range (1.8V to 5.5V) and industrial-grade temperature up to 105°C, enabling broader application scenarios.
