產品資訊
| item | Mode | Gate Driver | VIN | LDO | VDD | Max Freq | ADC | Capture | OPA | Operation Temp | Package |
|---|---|---|---|---|---|---|---|---|---|---|---|
| CGH001A | Hall | NA | 5V | NA | 4.5~5.5V | 48MHz | 10Bit、8-CH | 1 CH、16-Bit | 1 | -40~105 | SSOP28、QFN32 |
| CGH021A | Hall | 40V/ P/N | 40V | 5V/30mA | 4.5~5.5V | 48MHz | 10Bit、8-CH | 1 CH、16-Bit | 1 | -40~105 | QFN40 |
| CGH081A | Hall | 600V N/N | 15V | 5V/30mA | 4.5~5.5V | 48MHz | 10Bit、8-CH | 1 CH、16-Bit | 1 | -40~105 | LQFP48 |
| CGF002A | FOC | NA | 5V | NA | 4.5~5.5V | 48MHz | 10Bit、8-CH | 1 CH、16-Bit | 1 | -40~105 | LQFP48 |
| CGF022A | FOC | 40V/ P/N | 40V | 5V/30mA | 4.5~5.5V | 48MHz | 10Bit、8-CH | 1 CH、16-Bit | 1 | -40~105 | LQFP48 |
| CGF082A | FOC | 600V N/N | 15V | 5V/30mA | 4.5~5.5V | 48MHz | 10Bit、8-CH | 1 CH、16-Bit | 1 | -40~105 | LQFP48 |
